Parameter Description
Buzzer Sets the sound volume of the buzzer
Automatic
heating
If select “On”, when the ber is placed into heat oven, which will
automatically execute heating.
Language Sets a language to be displayed on the screen.
Auto Rotate
Screen
When you press "ON" in the system setting menu, the screen can
auto rotate the screen.
Power Save
Option
Sets the time of Monitor Shut Down, time of Splicer Shut Down
and LCD brightness.
Set Calendar Sets the system time.
Password
Changes the password to access some menus as “Power on
Option” and “Menu Lock”.
At the time of shipment from the factory, the password is set as
“0000”.
If you have forgotten your password after you changed another
one,
contact the nearest sales agency.
Pull test
If you select “ON”, pull test will be performed after fusion splicing
completion.
Dust check
Dust check: check dust and contaminants in optical path to avoid
optical ber inspection disturbance. If contaminants exist, press
conrm key to display the contaminants’ position.
Password lock
“On”: passwords are needed to input for entering into the fusion
splicing window when power on. “OFF”: No passwords are
needed when power on.
System
information
Display fusion splicer’s basic information: Machine serial NO.,
Software version, FPGA version, total Arc count, current Arc
count, Last maintenance, Production date, Sales Region, Product
OEM.
8.6 Auto Rotate Screen
When you press "ON" in the system setting menu, the screen can auto rotate the
screen.
8.7 Power Save Option
This function is important for power conservation. If the power saving function is
not set during battery pack use, the number of splice cycles will be reduced.
(1) Insert a power unit and turn on the splicer.
(2) Select “Power Save Option” in “System Setting” menu.
(3) Change values of “Monitor Shut Down” and “Splicer Shut Down”.
Parameter Description
Monitor Shut Down
To avoid power loss when battery is used, setting this function turns o
the power supply to the LCD monitor if the splicer does not operate after
a certain period of time. When the power supply for monitor turns o, the
LED near the power key blinks. Press any key to turn on the LCD monitor.
Splicer Shut Down
Automatically turns o the power supply of the splicer if it performs no
operation for a certain period of time. The function serves to prevent the
battery capacity from running low if the splicer is left on for an extended
period of time.
LCD Brightness Adjust LED backlight brightness.
