FiberHome AN5506-04-F User Manual

2 Appearance Description
Version A 2-3
LED
Indicator
Meaning Color Status Description
Off
The device is
powered off.
PON
Indicator of
registration
status
Green
On
The device
registers to the
GPON system.
Off
The device fails to
register to the
GPON system.
LOS
Indicator of
optical
signal status
Red
On
The device fails to
receive the optical
signal.
Off
The device
receives the
optical signal.
WIFI
Indicator of
wireless
signal
statatus
Green
Blinking
Data is being
transmitted or
received at this
interface.
Off
The WIFI service
is disabled.
On
The WIFI service
is enabled.
LAN1/2/3/4
Indicator of
Ethernet
status
Green
On
This interface is
connected to the
user terminal but
there is no data
transmission.
Blinking
Data is being
transmitted or
received at this
interface.
Off
This interface is
not connected to
the user terminal.
CATV
Indicator of
CATV status
Green
(1550
nm)
On
Optical power: -8
to +2
Blinking
Optical power: -25
to -8
Off
Indicationg
others.
