AN5506-04-F GPON Optical Network Unit User Manual
3-8 Version A
3.3.5 Connecting the Power Cable
The AN5506-04-F provides two types of power adapters: a power
adapter with three pins and a power adapter with battery.
Connecting the Power with Three Pins
1) Take out the power adapter with three pins included in the package.
2) Connect one end of the adapter to the Power interface of the
AN5506-04-F.
3) Connect the other end to the mains supply socket. See Figure 3-2.
The connection of power cable is complete.
ļ Note: This power adapter can convert 220V AC into 12V DC
input, to provide power supply for the AN5506-04-F.
Connecting the Storage Battery Power
Storage battery power adapter integrates a DC storage battery, which
enables the device to keep running for 6 to 7 hours in case of power
cutoff. This function improves operation reliability of the device.
Follow these steps to connect the power cable:
1) Take out the storage battery power adapter included in the package.
2) Connect one end of the adapter to the Power interface of the
AN5506-04-F.
3) Connect the other end to the mains supply socket. See Figure 3-6.
The connection of power cable is complete.
