2 Appearance Description
Version A 2-5
Table 2-2 Interfaces and buttons of the AN5506-04-G1
Interface
or Button
Meaning Type Description
Power switch Button
Turn on or off the
power.
Power
Power
interface
Power
interface
with three
pins
For connecting the AC
power adapter with
three pins or power
adapter with storage
battery.
USB
USB
interface
USB 2.0
For connecting a USB
terminal device.
CATV
CATV
interface
RF
For connecting a TV or
STB. Owned by the
AN5506-04-G1.
LAN1/2/3/
4
Ethernet
interface
RJ-45
For connecting a PC or
a router.
Console
Network
interface for
local
debugging
RJ-45
For local device
debugging. Not open to
the user.
PON
Optical
interface
SC/APC
Note
For connecting the
ODN.
Phone1/2
Phone
interface
RJ-11
For connecting a
phone.
RTS Reset button Button Reset manually.
WIFI
Wireless
switch
Button
Switch on / off wireless
function
Note: The PON interface type of the AN5506-04-F1 is SC/PC.
