AN5506-04-F GPON Optical Network Unit User Manual
3-2 Version A
The installation position should be well-ventilated, for convenient
heat dissipation.
3.2 Placing the Device
The AN5506-04-F can be placed on a stable plane (such as a desk), or
be hung on the wall. You can select the suitable installation mode. The
AN5506-04-F can be placed in the two modes as follows.
3.2.1 Placing the Device on a Platform
1) Take out the AN5506-04-F device from the carton. Before delivery,
four rubber pads are pasted to the four corners on the bottom of the
device.
2) Gently place the AN5506-04-F on a stable platform and ensure
ventilation on both right and left sides.
3.2.2 Mounting the Device on the Wall
1) According to the recesses distance (114 mm) marked in Figure 3-1,
fix two wall-mounted screws into the wall.
2) Align the recesses on the bottom panel of the AN5506-04-F with the
screws and fix it up gently.
3) The AN5506-04-F is mounted on the wall with the support of the
screws.
