AN5506-04-F GPON Optical Network Unit User Manual
3-6 Version A
The connection of the CATV cable is complete.
3.3.4 Connecting the Fiber
The AN5506-04-F adopts wavelength division multiplexing (WDM) mode
and provides “triple-play” integrated access. See Figure 3-2. The
connection steps of optical fibers are as follows.
1) Remove the fiber cover. See Figure 3-3.
Figure 3-3 Fiber connection (1)
2) Wrap the fiber jumper along the groove on the bottom panel and
insert one end to the PON interface of the AN5506-04-F. See Figure
3-4.
