2 Overview
2.1 Introduction
The L830 is a highly integrated 4G cellular module which uses the standard PCIe M.2 interface.It supports
LTE FDD/WCDMA mode cellular communication.
2.2 Specification
Specification
Operating Band
LTE FDD: Band 1,3,7,8,20,28,32
WCDMA/HSPA+: Band I, VIII
GPS/GLONASS: Not Support
CA
LTE inter-band CA
1 +3,7,20
3 +7,8,20,28,32
7 +20,28
LTE intra-band CA 3,7
Data Transmission
LTE FDD
300Mbps DL/50Mbps UL(Cat 6)
UMTS/HSPA+
UMTS:384 kbps DL/384 kbps UL
DC-HSDPA+:42Mbps DL(Cat 24)/5.76Mbps UL(Cat6)
Power Supply DC 3.135V～4.4V, Typical 3.3V
Temperature
Normal Operating temperature
：
-10°C
～
+55°C
Extended Operating temperature
：
-30°C
～
+65°C
Storage temperature：-40°C ～+85°C
Physical
characteristics
Interface: M.2 Key-B
Dimension
：
30 x 42 x 2.3mm
Weight: About 5.8 g
Interface
Antenna Connector
WWAN Main Antenna x 1
WWAN Diversity Antenna x 1
Function Interface
USIM 3V/1.8V
