Mode
Band
3GPP Requirement
Rx Sensitivity(dBm)
Typical
Note
Band VIII
-103.7
-110.5
BER<0.1%
LTE FDD
Band 1
-96.3
-101
10MHz Bandwidth
Band 3
-93.3
-101
10MHz Bandwidth
Band 7
-94.3
-101.5
10MHz Bandwidth
Band 8
-93.3
-101
10MHz Bandwidth
Band 20
-93.3
-101
10MHz Bandwidth
Band 28
-94.8
-101
10MHz Bandwidth
Band 32
-96.5
TBD
10MHz Bandwidth
Note:
The above values are measured for the dual antennas situation (Main + Diversity). For single
main antenna (without Diversity), the sensitivity will drop around 3dBm for each band of LTE.
4.5 GNSS
L830-EB-11 module not support GNSS.
4.6 Antenna Design
The L830 module provides main and diversity antenna interfaces, and the antenna design requirements
as shown in the following table:
L830 module Main antenna requirements
Frequency range
The most proper antenna to adapt the frequencies should be used.
Bandwidth(WCDMA)
WCDMA band I(2100) : 250 MHz
WCDMA band VIII(900) : 80 MHz
Bandwidth(LTE)
LTE band 1(2100): 250 MHz
LTE Band 3(1800): 170 MHz
LTE band 7(2600): 190 MHz
LTE Band 8(900): 80 MHz
LTE band 20(800): 71 MHz
LTE band 28(850): 100 MHz
LTE band 32(700): 11 MHz
Impedance
50 Ohm
