L830-EB-11 Hardware User Manual Page 13 of 39
Pin
Pin Name
I/O
Reset
Value
Pin Description
Type
48
TX_BLANKING
O
L
TDMA Timer output, external GPS
control signal.(not supported)
CMOS 1.8V
49
NC
NC
50
NC
NC
51
GND
GND
Power Supply
52
NC
NC
53
NC
NC
54
NC
NC
55
NC
NC
56
NC
NC
57
GND
GND
Power Supply
58
NC
NC
59
ANTCTL0
O
L
Tunable antenna control signal, bit0
(not supported yet).
CMOS 1.8V
60
COEX3
O
Reserved
61
ANTCTL1
O
L
Tunable antenna control signal, MIPI
RFFE SDATA, bit1 (not supported
yet).
CMOS 1.8V
62
COEX2
O
Reserved
63
ANTCTL2
O
L
Tunable antenna control signal, MIPI
RFFE SCLK, bit2 (not supported
yet).
CMOS 1.8V
64
COEX1
O
Reserved
65
ANTCTL3
O
Tunable antenna control signal, MIPI
RFFE VIO, bit3 (not supported yet).
CMOS 1.8V
66
SIM_DETECT
I
SIM card detect, external 390KΩ
pull-up.
CMOS 1.8V
67
RESET#
I
External reset input signal, internal
100KΩ pull-up.
CMOS 1.8V
68
NC
NC
69
CONFIG_1
O
L
Connected to internal GND, L830
