10
CALIBRATION
! Device must be calibrated to your specific laser engraver to function properly.
! Failure to calibrate the device prior to usage may significantly reduce the life of
your filters.
Once your Filtrabox has been UNLOCKED with the AUTHENTICATION CODE, it
is ready to be CALIBRATED to your specific laser engraver.
1. First, hook up the Filtrabox fume extractor to the Laser Engraver, with the supplied hose or
with the hose you intend to permanently use for the application. Arrange the laser, Filtrabox
and the hoses into their desired locations. This is important because the calibration process
takes the restrictions caused by the bends in the hose and positioning of the equipment into
account.
2. ! Pressing the “OK” button will trigger the Calibration process which will take
approximately one minute. If the calibration process fails, try restarting the system and
ensuring that nothing is obstructing the inlet or hose. If the calibration process continues to
fail, contact Filtrabox Technical support for help.
3. If you have previously set the number of blowers and wish only to Calibrate Filtrabox to a
new application, press the “Menu” button. Press the right arrow key to advance the screen
until you reach the “New Application Calibration” section. Press the “OK” button to initiate
Calibration. The Calibration process will take approximately one minute.
