REPLACING THE OXY-CARBON GAS FILTER FIL-G-CX-407
! Replacement filters can be purchased from your dealer or: info@filtrabox.com
or call 514.840.9696 ext. 102
! When laser odor becomes evident, it is time to change the GAS FILTER.
! To avoid any risk of electrical discharge, turn off and unplug the Filtrabox
before doing any activities that require disassembly of the unit.
! Attention: The OXY-Carbon Gas Filter is HEAVY. Each filter weighs
approximately 50lbs each. Take appropriate care and precaution when lifting
the filter.
1. Loosen all four Strap Clamps on the Lid by pressing the lever on the clamps. Unhook the Strap
Clamps and remove the Lid by lifting it straight up off the assembly.
2. Set aside the three Filter Alignment Rings, the Pre-Filter, and the HEPA Filter.
3. Remove and replace the old Gas Filter and ensure that the new one is centered correctly onto
the Base Module.
4. Replace one of the Filter Alignment Rings (they are all the same) that was set aside earlier onto
the new Gas Filter and that it is oriented the right way up.
5. Replace the HEPA Filter and the next Filter Alignment Ring that were set aside earlier onto the
new Gas Filter and that it is oriented the right way up.
6. Replace the Pre-Filter and the topmost Filter Alignment Ring that were set aside earlier onto
the HEPA Filter and that it is oriented the right way up.
7. Ensure that all the Filters are the right side up by following the labels.
8. Replace the Lid back onto the machine and tighten all four Strap Clamps back onto the hooks.
9. Check the Machine Diagram on page 4 if necessary.
