Fimap MR65 B - Recovery Tank; Solution Tank; Filling the Solution Tank

18
MACHINE PREPARATION
20.
RECOVERY TANK
Make sure the recovery tank is empty, otherwise empty
it completely.
Check the cap of the drainage tube (10) (on the rear of the machine) is correctly closed.
21.
SOLUTION TANK
The recovery tank must be completely empty each time the solution tank is filled.
Remove the front inlet cap and
check the solution filter is correctly fitted.
Check that the solution filter cap (1), under the solution tank in the front right of the machine, is properly closed.
22.
FILLING THE SOLUTION TANK
The solution tank can be filled in three
different ways:
1. Unscrew the filler cap (1) and fill using a hose.
2.
Using the rubber cap (2), this supports the water hose on its own, be sure to unscrew the cap to allow the
proper vent of air.
3.
Using on request (optional) a tank clean
water refilling system via a quick coupling (3), FFF with float to
control the overflow.
1
1
2
3
