Fimap MR65 B - Technical Description

6
TECHNICAL DESCRIPTION
U/M MR60 B MR65 B MR75 B
Nominal input power [IEC 60335-2-72; IEC 62885-9] kW 1,31 1,81 1,81
Working width mm 615 660 760
Squeegee width mm 800 990 990
Working capacity, up to m
2
/h 3320 3565 4105
Disc brushes
No. / mm
1 / 610 2 / 340 2 / 390
Brush rpm rpm 140 140 140
Brush motor n/(V/W) 1/(24/500) 2/(24/500) 2/(24/500)
Force exerted on brush N 294 294–588 294–588
Traction motor V/W 24/400 24/400 24/400
Traction wheel
 mm
220 220 220
Forward speed km/h
06 06 06
Maximum gradient with full load % 10 10 10
Suction motor V/W 24/410 24/410 24/410
Maximum vacuum [IEC 62885-9; IEC 60312-1] kPa 10,6 10,6 10,6
Rear elastic wheels
 mm
300x70 300x70 300x70
Solution tank l 110 110 110
Recovery tank l 125 125 125
Detergent tank (FSS version only) l
-
5 5
Steering diameter mm 2360 2360 2360
Machine dimensions (Length / Height / Width) mm 1510x1320x680 1510x1320x685 1510x1320x780
Battery compartment dimensions (Length / Height / Width) mm 525x350x390 525x350x390 525x350x390
Recommended battery (6 MFP 180) V / AhC
5
6/180 6/180 6/180
Recommended battery weight kg 31 31 31
Machine weight when empty kg 223 223 223
Transported machine weight kg 350 350 350
Machine weight in running order kg 550 550 550
Sound pressure level in operator seat [ISO 11201] (LpA) dB
61,5 61,5 61,5
Uncertainty K
pA
dB 1.4 1.4 1.4
Whole body vibrations [IEC 60335-2-72; IEC 62885-9; ISO 2631-1] m/s
2
<0,5 <0,5 <0,5
Hand-arm vibrations [IEC 60335-2-72; IEC 62885-9; ISO 5349-1] m/s
2
<2.5 <2.5 <2.5
Uncertainty
3,5% 3,5% 3,5%
