Fimap MR65 B - Page 7

7
TECHNICAL DESCRIPTION
U/M MR85 B MR100 B
Nominal input power [IEC 60335-2-72; IEC 62885-9] kW 1,81 2,01
Working width mm 845 1020
Squeegee width mm 1105 1105
Working capacity, up to m
2
/h 4565 5510
Disc brushes
No. / mm
2/430 2/510
Brush rpm rpm 140 120
Brush motor n/(V/W) 2/(24/500) 2/(24/600)
Force exerted on brush N 294–588 294
Traction motor V/W 24/400 24/400
Traction wheel
 mm
220 220
Forward speed km/h
06 06
Maximum gradient with full load % 10 10
Suction motor V/W 24/410 24/410
Maximum vacuum [IEC 62885-9; IEC 60312-1] kPa 10,6 10,6
Rear elastic wheels
 mm
300x70 300x70
Solution tank l 110 110
Recovery tank l 125 125
Detergent tank (CDS version only) l 5 5
Steering diameter mm 2360 2360
Machine dimensions (Length / Height / Width) mm 1510x1320x855 1510x1320x1035
Battery compartment dimensions (Length / Height / Width) mm 525x350x390 525x350x390
Recommended battery (6 MFP 180) V / AhC
5
6/180 6/180
Recommended battery weight kg 31 31
Machine weight when empty kg 223 233
Transported machine weight kg 350 360
Machine weight in running order kg 550 560
Sound pressure level in operator seat [ISO 11201] (LpA) dB
61,5 61,5
Uncertainty K
pA
dB 1.4 1.4
Whole body vibrations [IEC 60335-2-72; IEC 62885-9; ISO 2631-1] m/s
2
<0,5
<0,5
Hand-arm vibrations [IEC 60335-2-72; IEC 62885-9; ISO 5349-1] m/s
2
<2.5
<2.5
Uncertainty
3,5%
3,5%
