FineTek EPD30 - Page 14

11
Connection
specification
JIS 7.50K
Nominal diameter(mm)
50
80
100
125
150
200
250
300
Lining material
PTFE
Length
L
200
200
250
250
300
350
400
500
External diameter
ϕD
155
211
238
263
290
342
410
464
PCD
ϕC
120
168
185
225
247
299
360
414
Flange thickness
t
18
21
24
26
23
24
26
28
Inclined angle of screw
hole
θ°
45
45
45
30
30
22.5
22.5
18
Diameter of screw hole
θh
19
19
19
19
19
19
23
23
Quantity of screw holes
N
4
4
4
6
6
8
8
10
Height of sensor casing
H1
125
145
195
195
270
305
365
406
Total height
H2
322
360
399
411
472
511
577
625
Weight (kg)
-
7.65
12.45
15.82
19.55
25.63
36.82
55.63
74.95
Remarks: For DN40~DN80, the lining protective ring is 2mm, so the total length of the flow meter shall be
increased by L+4mm. For DN100~DN300, the lining protective ring is 0.5mm, so the total length of the flow
meter shall be increased by L+1mm; total length (L) tolerance is ±3mm, total height (H2) tolerance is ±5mm
