FineTek EPD30 - Various Parameter Setting Ranges

22
Parameter Setting Page
Button
Main Measuring
Page
Menu Mode
Read Only
Number Edit
Mode
List Edit Mode
ENT
Enter menu
Enter sub menu
Confirm button
(Keep pressing)
Confirm button
(Keep pressing)
<
Return to the
previous page
Return to the
previous page
"Left" button
Return to the
previous page
^
Sub menu option
【Down】
Number: "Plus"
button
Option: Next
page
ENT+ <
Cancel
14.2 Various Parameter Setting Ranges
Main Menu
Sub Menu
Unit
Default
Setting Range
Fast Set (0)
Device Tag Num (1.1)
The parameter is linking from standard menu
Zero Adj.(2.1)
Flow Span (1.5)
Flow Unit (1.4)
Low cutoff (2.4)
Damping Time (3.1)
Pulse Out Unit (3.3)
Total Reset (1.9)
Main Menu
Sub Menu
Unit
Default
Setting Range
Basic Set
(1)
Device Tag Num (1.1)
none
00001
00001~65535
Measure Type (1.2)
-
Water
Water
Tube Size (1.3)
mm
actual
10,15,25,32,40,50,65,80,100
125,150,200,250,300,350,400,450,500
Flow Unit (1.4)
-
m
3
/h
L/(s,min,h),m
3
/(s,min,h),gal/(s,min,h),
kg(s,min,h),Ton(s,min,h)
(Flow rate* Liquid density = weight)
"L/s","L/m","L/h","m
3
/s","m
3
/m","m
3
/h",
"gal/s","gal/m","gal/h","kg/s","kg/m",
"kg/h","Ton/s","Ton/m","Ton/h"," m
3
/d"
Flow Span (1.5)
=Flow Rate
Unit
(5m/s ) x
(Diameter/2)
2
x pi
x Unit of Flow
(0.1 ~ 10.0m/s ) x (Diameter/2)
2
x pi
x Unit of Flow (000.00)
Direction (1.6)
dir
Forward
Forward,Reverse
Total Unit (1.7)
-
m
3
Liter,gal, m
3
,kg,Ton
Total Mode (1.8)
none
Forward
Forward,Reverse,Bi-direction
Total Reset (1.9)
none
Cancel
Cancel,Accept
