FineTek EPD30 - Page 26

23
Main Menu
Sub Menu
Unit
Default
Setting Range
Advanced
Set (2)
Zero Adj. (2.1)
m/s
actual
-0.5000~+0.5000
K-Factor (2.2)
none
1.000
0.000~3.000
Density (2.3)
g/㎤
1.0000
0.0001~9.9999
Low cutoff (2.4)
%
0.5
0.00~100.00
Fwd. Init. (2.5)
=Total Unit
0
0~9999999999
Rev. Init. (2.6)
=Total Unit
0
0~9999999999
Main Menu
Sub Menu
Unit
Default
Setting Range
I/O Signal
Set (3)
Damping Time (3.1)
second
3
0~100
Pulse Out Mode (3.2)
none
Pulse NO
Pulse NO, Pulse NC, Frequency
Pulse Out Unit (3.3)
Unit/pulse
0.1 L
0.001~100(L,gal, m
3
,g,kg,Ton)
L/pulse,gal/pulse,m3/pulse,g/pulse,kg/pulse,
Ton/pulse
Max. Freq. (3.4)
kHz
2K
0.001~8K (00.000)
Curr. Mode (3.5)
none
4-20
4-20,0-20
4mA Fine-Tune (3.6)
count
0
-5000~5000
20mA Fine-Tune (3.7)
count
0
-5000~5000
Input1 Func. (3.8)
N/A
None
None, Total Reset
Input1 Type (3.9)
N/A
NO
NO,NC
Filter Variation(3.10)
m/s
1
00.000~10.000
Filter Weight(3.11)
%
10
0~100
Main Menu
Sub Menu
Unit
Default
Setting Range
Alarm Set
(4)
Max. Flow (4.1)
Flow Rate
Unit
Max.
Max. Flow Rate
Min. Flow (4.2)
Flow Rate
Unit
min.
Min. Flow Rate
Empty Tube Set (4.3)
N/A
Disable
Enable, Disable
Output 1 Func. (4.4)
N/A
Max. Flow
Rate
Max. Flow Rate, Min. Flow Rate, Empty Tube,
System Alarm
Output 1 Type (4.5)
N/A
NO
NO,NC
Output 2 Func. (4.6)
N/A
Min. Flow
Rate
Max. Flow Rate, Min. Flow Rate, Empty Tube,
System Alarm
Output 2 Type (4.7)
N/A
NO
NO,NC
Curr. Func. (4.8)
N/A
None
Empty Tube, System Alarm
Alarm Curr. (4.9)
mA
3.6
3.6,3.8,20.5,22
Temp. Alarm.(4.10)
N/A
1
0: OFF, 1: ON
