FineTek EPD30 - MODBUS Communication Protocol

31
18. MODBUS Communication Protocol
Address(Hex)
Address(Dec)
Variable Name
Data Type
Unit
Range
Definition
Authority
0x1000
4096
gt_modbus_slave_fine_tek_id[0]
UINT8
N/A
"FI"
Read
only(Header)
0x1001
4097
gt_modbus_slave_fine_tek_id[2]
UINT8
N/A
"NE"
Read
only(Header)
0x1002
4098
gt_modbus_slave_fine_tek_id[4]
UINT8
N/A
"-T"
Read
only(Header)
0x1003
4099
gt_modbus_slave_fine_tek_id[6]
UINT8
N/A
"EK"
Read
only(Header)
0x1004
4100
PFC_PRODUCT_TYPE
UINT16
N/A
"FM"
Read
only(Header)
0x1005
4101
PFC_PRODUCT_NUMBER
UINT16
N/A
0x0001
Read
only(Header)
0x1006
4102
PFC_PRODUCT_VERSION
UINT16
N/A
0x0001
Read
only(Header)
0x1010
Measuring Status
Data Type
Unit
Range
Definition
Authority
0x1010
4112
PFC_FlowTotal_FRAM_FWD_VAL-High
FLOAT64
m
3
Forward accumulated flow
capacity
Read only
0x1011
4113
PFC_FlowTotal_FRAM_FWD_VAL+1
Read only
0x1012
4114
PFC_FlowTotal_FRAM_FWD_VAL+2
Read only
0x1013
4115
PFC_FlowTotal_FRAM_FWD_VAL-Low
Read only
0x1014
4116
PFC_FlowTotal_FRAM_REV_VAL-High
FLOAT64
m
3
Backward accumulated flow
capacity
Read only
0x1015
4117
PFC_FlowTotal_FRAM_REV_VAL+1
Read only
0x1016
4118
PFC_FlowTotal_FRAM_REV_VAL+2
Read only
0x1017
4119
PFC_FlowTotal_FRAM_REV_VAL-Low
Read only
0x1018
4120
PFC_FlowTotal_FRAM_BI_DIR_VAL-High
FLOAT64
m
3
Two-way accumulated flow
capacity
Read only
0x1019
4121
PFC_FlowTotal_FRAM_BI_DIR_VAL+1
Read only
0x101A
4122
PFC_FlowTotal_FRAM_BI_DIR_VAL+2
Read only
0x101B
4123
PFC_FlowTotal_FRAM_BI_DIR_VAL-Low
Read only
0x101C
4124
PFC_FlowRate_Main_Val-High
FLOAT64
Rate
Unit
Instant flow rate value
Read only
0x101D
4125
PFC_FlowRate_Main_Val+1
Read only
0x101E
4126
PFC_FlowRate_Main_Val+2
Read only
0x101F
4127
PFC_FlowRate_Main_Val-Low
Read only
0x1020
4128
gb_pfc_flowrate_rawdata_m_s-High
FLOAT64
m/s
\Setting\ Information\ Actual flow
rate
Read only
0x1021
4129
gb_pfc_flowrate_rawdata_m_s+1
Read only
0x1022
4130
gb_pfc_flowrate_rawdata_m_s+2
Read only
0x1023
4131
gb_pfc_flowrate_rawdata_m_s-Low
Read only
0x1024
4132
gf_pfc_current_out_value-High
FLOAT32
mA
Output current value
Read only
0x1025
4133
gf_pfc_current_out_value-Low
Read only
0x1026
4134
PFC_SIMULATION_INPUT_CURR-High
FLOAT32
mA
Iutput current value
Read only
0x1027
4135
PFC_SIMULATION_INPUT_CURR-Low
Read only
0x1028
4136
gb_pfc_liquid_resistance-High
FLOAT32
KΩ
\Setting\ Information\ Liquid
resistance value
Read only
0x1029
4137
gb_pfc_liquid_resistance-Low
Read only
0x102A
4138
PFC_FlowTotal_FWD_VAL-Low
UINT32
Liter
Forward accumulated flow
capacity
Read only
0x102B
4139
PFC_FlowTotal_FWD_VAL-High
Read only
0x102C
4140
PFC_FlowTotal_REV_VAL-Low
UINT32
Liter
Backward accumulated flow
capacity
Read only
0x102D
4141
PFC_FlowTotal_REV_VAL-High
Read only
0x102E
4142
PFC_FlowTotal_BI_VAL-Low
UINT32
Liter
Two-way accumulated flow
capacity
Read only
0x102F
4143
PFC_FlowTotal_BI_VAL-High
Read only
0x1030
4144
PFC_Flowrate_Main_Vluae-Low
FLOAT32
Rate
Unit
Instant flow rate value
Read only
0x1031
4145
PFC_Flowrate_Main_Vluae-High
Read only
0x1032
4146
PFC_Flowrate_rawdata_vluae-Low
FLOAT32
m/s
\Setting\ Information\ Actual flow
rate
Read only
0x1033
4147
PFC_Flowrate_rawdata_vluae-High
Read only
