32
0x1040
System status
Data Type
Unit
Range
Definition
Authority
0x1040
4160
PFC_TEMPERATURE_BOARD_NOW-High
FLOAT32
o
C
PCB temp.
Read only
0x1041
4161
PFC_TEMPERATURE_BOARD_NOW-Low
Read only
0x1042
4162
PFC_SELF_TEST_TUBE_STATUS
UINT16
N/A
0: Normal
1: Empty
\Setting\ Information\ Status of pipe
Read only
0x1043
4163
pfc_system_status_code_value-High
UINT32
N/A
\Setting\ Information\ system status
code
Read only
0x1044
4164
pfc_system_status_code_value-Low
Read only
0x1050
Paramter setting- System information
Data Type
Unit
Range
Definition
Authority
0x1050
4176
PFC_PRODUCT_VERSION
UINT16
N/A
Version of firmware (Master)
Read only
0x1055
Parameter setting- Basic setting
Data Type
Unit
Range
Definition
Authority
0x1055
4181
PFC_BASIC_SET_DEVICE_TAG_NUM
UINT16
N/A
00001~65535(Default:1)
Basic setting/ ID number
Read /Write
0x1056
4182
PFC_BASIC_SET_MEASURE_TYPE
N/A
0:Water 1:none
Measured object
Read /Write
0x1057
4183
PFC_BASIC_SET_TUBE_SIZE-High
FLOAT32
10~100mm
Line size divided by 1000
Basic setting/ Connection
size
Read /Write
0x1058
4184
PFC_BASIC_SET_TUBE_SIZE-Low
125~500mm
e.g.: DN80= 80/1000=0.08
0x1059
4185
PFC_BASIC_SET_FLOW_RATE_UNIT
UINT16
N/A
0:L/m
1:L/h
2:m3/m
3:m3/h
4:gal/m
5:gal/h
6:kg/m
7:kg/h
8:T/m
9:T/h
10:m3/d
Basic setting/Instant flow
rate unit
Read /Write
0x105A
4186
PFC_BASIC_SET_FLOW_SPAN-High
FLOAT64
m
3
/s
+Line size(m)^2 *0.0785
~ Line size(m)^2 *7.85
Basic setting/Measuring
range of full pipe
Read /Write
0x105B
4187
PFC_BASIC_SET_FLOW_SPAN+1
Read /Write
0x105C
4188
PFC_BASIC_SET_FLOW_SPAN+2
Read /Write
0x105D
4189
PFC_BASIC_SET_FLOW_SPAN-Low
Read /Write
0x105E
4190
PFC_BASIC_SET_FLOW_DIR
UINT16
N/A
0: Forward
1: Backward
Basic setting/Flow
direction
Read /Write
0x105F
4191
PFC_BASIC_SET_FLOW_TOTAL_UNIT
UINT16
N/A
0:Liter1:gal2:m33:kg4:Ton
Basic setting/
Accumulated flow
capacity unit
Read /Write
0x1060
4192
PFC_BASIC_SET_TOTAL_MODE
UINT16
N/A
0: Forward
1: Backward
2: Two-way
Basic setting/
Accumulated flow
capacity mode
Read /Write
0x1061
4193
PFC_BASIC_SET_TOTAL_RESET
UINT16
N/A
0: Cancel
1: Confirm
Basic setting/ Reset
accumulated flow
capacity
Read /Write
