37
0x10C9
Parameter setting- Analog Simulation
Data Type
Unit
Range
Definition
Authority
0x10C9
4297
PFC_SIMULATION_FUNC_STATE
UINT16
N/A
0:None
1: Flow rate
2: Flow capacity
3: Current output
4: Frequency output
5: Output1 status
6: Output2 status
Simulation fuction select
Read /Write
0x10CA
4298
PFC_SIMULATION_FLOW_SPEED-High
FLOAT64
m/s
-10.000~10.000
Simulation of flow rate
Read /Write
0x10CB
4299
PFC_SIMULATION_FLOW_SPEED+1
Read /Write
0x10CC
4300
PFC_SIMULATION_FLOW_SPEED+2
Read /Write
0x10CD
4301
PFC_SIMULATION_FLOW_SPEED-Low
Read /Write
0x10CE
4302
PFC_SIMULATION_FLOW_RATE-High
FLOAT642
Rate
Unit
+0.0000 ~ 口徑(m)^2
*7.85
Simulation of flow capacity
Read /Write
0x10CF
4303
PFC_SIMULATION_FLOW_RATE+1
Read /Write
0x10D0
4304
PFC_SIMULATION_FLOW_RATE+2
Read /Write
0x10D1
4305
PFC_SIMULATION_FLOW_RATE-Low
Read /Write
0x10D2
4306
PFC_SIMULATION_OUTPUT_CURR-High
FLOAT32
mA
3.6~22
Simulation of current output
Read /Write
0x10D3
4307
PFC_SIMULATION_OUTPUT_CURR-Low
Read /Write
0x10D4
4308
PFC_SIMULATION_OUTPUT_FREQ
UINT16
Khz
0.002~8Khz
Simulation of frequency
output
Read /Write
0x10D5
4309
PFC_SIMULATION_OUTPUT_1_STATUS
UINT16
N/A
0: OPEN
1: CLOSED
Simulation of output1 status
Read /Write
0x10D6
4310
PFC_SIMULATION_OUTPUT_2_STATUS
UINT16
N/A
0: OPEN
1: CLOSED
Simulation of output2 status
Read /Write
0x10DE
System specific setting
Data Type
Unit
Range
Definition
Authority
0x10DE
4318
PFC_SAVE_SYSTEM_VAR_TO_EEPROM
UINT16
N/A
0: none
1: Input
Input USER EEPROM
Read /Write
0x10DF
4319
PFC_ENG_MODE_SAVE_SETTING
UINT16
N/A
0: none
1: Input
Input FACTORY; Set EEPROM
Read /Write
0x10E0
4320
pfc_auto_set_excition_freq_flag
UINT16
N/A
0: Off
1: On
Auto input excitation frequency
accoring to frequency and pipe size
Read /Write
