List of fuses
01 - (F101) - Courtesy light and socket power supply.
02 - (F102) - Power supply for arm lowering enable, relay (K101).
03 - (F103) - Power supply for front windscreen wipers, rear windscreen wipers and windscreen washer
pump control.
04 - (F104) - Power supply for water pump control, litre counter sensor, relay (K102).
05 - (F105) - Power supply for heating fan control.
06 - (F106) - Relay power supply (K107).
07 - (F107) - Power supply for parking brake control, neutral enable on forward drive control, relay (K103),
neutral relay.
08 - (F108) - Power supply for acoustic indicator and rear camera (optional).
09 - (F109) - Power supply for direction indicators and stop light bulb.
10 - (F110) - Power supply for drum rotation control, frame rotation pressure gauge.
11 - (F111) - Power supply for water in the fuel, LCD instrument, 1st and 2nd gear warning lights, relay coil
(K107), relay coil (K108), relay coil (K111).
12 - (F112) - Front LH and rear RH position light, power supply for rear working light control
13 - (F113) - RH low beam headlight.
14 - (F114) - LH low beam headlight.
15 - (F115) - Power supply for additive pumps (optional).
16 - (F116) - Front RH and rear LH position light, position light indicator.
17 - (F117) - Power supply for weighing central unit (optional).
18 - (F118) - Power supply for emergency lights, rotating beacon control.
19 - (F119) - Relay power supply (K109).
20 - (F120) – Relay power supply (K110).
21 - (SPARE 1) - Spare fuse.
22 - (SPARE 2) - Spare fuse.
23 - (SPARE 3) - Spare fuse.
24 - EGR power.
25 - Diagnostics socket.
