Fire-Lite 411UD - Event Codes for Primary Central Station; Ademco Contact ID Format Event Codes (Primary); 4+2 Standard & 4+2 Express Formats (Primary)

Program Mode
28
411UD Document #50759 Rev. E 12/09/2008 P/N 50759:E
Ademco Contact ID Format Primary Central Station Event Codes
If 'E' is entered for address 20, the following data is automatically programmed for the Primary Central Station
phone number event codes. Enter '000' for the Setting to disable the report to the Central Station. The Channel #
is not programmable.
4+2 Standard and 4+2 Express Formats Primary Central Station Event Codes
If 1, A or C is entered for address 20, the following data is automatically programmed for the Primary Central Sta-
tion phone number event codes. Enter '00' for the Setting to disable the report to the Central Station.
TABLE 3-1: Ademco Contact ID Format - Primary
Address Description Setting
Channel/
Input #
138 - 140 Primary # Input Channel 1 Active Event Code 110 001
141 - 143 Primary # Input Channel 2 Active Event Code 373 002
144 - 146 Primary # Input Channel 3 Active Event Code 200 003
147 - 149 Primary # Input Channel 4 Active Event Code 301 004
150 - 152 Primary # Input Channel 1 Fault Event Code 380 001
153 - 155 Primary # Input Channel 2 Fault Event Code 380 002
156 - 158 Primary # Input Channel 3 Fault Event Code 380 003
159 - 161 Primary # Input Channel 4 Fault Event Code 380 004
162 - 164 Primary # Phone Line 1 Voltage Fault Event Code 351 000
165 - 167 Primary # Phone Line 2 Voltage Fault Event Code 352 000
168 - 170 Primary # Phone Number 1 Comm. Fault Event Code 354 001
171 - 173 Primary # Phone Number 2 Comm. Fault Event Code 354 002
174 - 176 Primary # System Off Normal Fault Code 308 000
177 - 179 Primary # System Test Message 602 000
180 - 182 Primary # System Abnormal Test Message 608 000
183 - 185 Primary # Upload/Download Request Code 411 000
186 - 188 Primary # Upload Successful Code 416 000
189 - 191 Primary # Download Successful Code 412 000
192 - 194 Primary # Upload/Download Failed Code 413 000
TABLE 3-2: 4+2 Standard and 4+2 Express Formats - Primary
Address Description Setting
138 - 139 Primary # Input Channel 1 Active Event Code 11
140 - 141 Primary # Input Channel 2 Active Event Code FF
142 - 143 Primary # Input Channel 3 Active Event Code 83
144 - 145 Primary # Input Channel 4 Active Event Code 92
146 - 147 Primary # Input Channel 1 Fault Event Code F1
148 - 149 Primary # Input Channel 2 Fault Event Code F2
150 - 151 Primary # Input Channel 3 Fault Event Code F3
152 - 153 Primary # Input Channel 4 Fault Event Code F4
154 - 155 Primary # Phone Line 1 Voltage Fault Event Code 64
156 - 157 Primary # Phone Line 2 Voltage Fault Event Code 65
