Program Mode
32
411UD Document #50759 Rev. E 12/09/2008 P/N 50759:E
The following Tables list the data which is automatically programmed for each Format that can be selected in address
50. The addresses shown in each Table contain the event code Setting data which is automatically programmed by
the 411UD. To change the value, key in the new digits and then press the [ENTER/STORE] key to save the new
value. Use the Up and Down Arrow keys to increment to the next address or decrement to the previous address.
Ademco Contact ID Format Secondary Central Station Event Codes
If E is entered for address 50, the following data is automatically programmed for the Secondary Central Station
phone number event codes. Enter '000' for the Setting to disable the report to the Central Station.
4+2 Standard and 4+2 Express Formats Secondary Central Station Event Codes
If 1, A or C is entered for address 50, the following data is automatically programmed for the Secondary Central Sta-
tion phone number event codes. Enter '00' for the Setting to disable the report to the Central Station.
TABLE 3-4: Ademco Contact ID Format - Secondary
Address Description Setting
Channel/
Input #
202 - 204 Secondary # Input Channel 1 Active Event Code 110 001
205 - 207 Secondary # Input Channel 2 Active Event Code 373 002
208 - 210 Secondary # Input Channel 3 Active Event Code 200 003
211 - 213 Secondary # Input Channel 4 Active Event Code 301 004
214 - 216 Secondary # Input Channel 1 Fault Event Code 380 001
217 - 219 Secondary # Input Channel 2 Fault Event Code 380 002
220 - 222 Secondary # Input Channel 3 Fault Event Code 380 003
223 - 225 Secondary # Input Channel 4 Fault Event Code 380 004
226 - 228 Secondary # Phone Line 1 Voltage Fault Event Code 351 000
229 - 231 Secondary # Phone Line 2 Voltage Fault Event Code 352 000
232 - 234 Secondary # Phone Number 1 Comm. Fault Event Code 354 001
235 - 237 Secondary # Phone Number 2 Comm. Fault Event Code 354 002
238 - 240 Secondary # System Off Normal Fault Code 308 000
241 - 243 Secondary # System Test Message 602 000
244 - 246 Secondary # System Abnormal Test Message 608 000
247 - 249 Secondary # Upload/Download Request Code 411 000
250 - 252 Secondary # Upload Successful Code 416 000
253 - 255 Secondary # Download Successful Code 412 000
256 - 258 Secondary # Upload/Download Failed Code 413 000
TABLE 3-5: 4+2 Standard and 4+2 Express Formats - Secondary
Address Description Setting
202 - 203 Secondary # Input Channel 1 Active Event Code 11
204 - 205 Secondary # Input Channel 2 Active Event Code FF
206 - 207 Secondary # Input Channel 3 Active Event Code 83
208 - 209 Secondary # Input Channel 4 Active Event Code 92
210 - 211 Secondary # Input Channel 1 Fault Event Code F1
212 - 213 Secondary # Input Channel 2 Fault Event Code F2
214 - 215 Secondary # Input Channel 3 Fault Event Code F3
216 - 217 Secondary # Input Channel 4 Fault Event Code F4
