Fire-Lite 411UD - Event Codes for Expanded Formats (Secondary); 4+2 Standard & 4+2 Express Formats (Secondary) Continued; All 3+1, 4+1 and 4+2 Expanded Formats (Secondary)

411UD Document #50759 Rev. E 12/09/2008 P/N 50759:E 33
Program Mode
All 3+1, 4+1 and 4+2 Expanded Formats Secondary Central Station Event Codes
If 0, 2, 3, 4, 5, 6, 7, 8 ,9, B or D is entered for address 50, the following data is automatically programmed for the
Secondary Central Station phone number event codes. Enter '0' for the Setting to disable the report to the Central
Station.
218 - 219 Secondary # Phone Line 1 Voltage Fault Event Code 64
220 - 221 Secondary # Phone Line 2 Voltage Fault Event Code 65
222 - 223 Secondary # Phone Number 1 Comm. Fault Event Code 6A
224 - 225 Secondary # Phone Number 2 Comm. Fault Event Code 6B
226 - 227 Secondary # System Off Normal Fault Code 6F
228 - 229 Secondary # Input Channel 1 Active Restoral Code E1
230 - 231 Secondary # Input Channel 2 Active Restoral Code E2
232 - 233 Secondary # Input Channel 3 Active Restoral Code E3
234 - 235 Secondary # Input Channel 4 Active Restoral Code 93
236 - 237 Secondary # Input Channel 1 Fault Restoral Code D1
238 - 239 Secondary # Input Channel 2 Fault Restoral Code D2
240 - 241 Secondary # Input Channel 3 Fault Restoral Code D3
242 - 243 Secondary # Input Channel 4 Fault Restoral Code D4
244 - 245 Secondary # Phone Line 1 Restoral Code A4
246 - 247 Secondary # Phone Line 2 Restoral Code A5
248 - 249 Secondary # Phone Number 1 Restoral Code AA
250 - 251 Secondary # Phone Number 2 Restoral Code AB
252 - 253 Secondary # System Off Normal Restoral Code AF
254 - 255 Secondary # System Test Message 99
256 - 257 Secondary # System Abnormal Test Message 91
258 - 259 Secondary # Upload/Download Request Code 71
260 - 261 Secondary # Upload Successful Code 72
262 - 263 Secondary # Download Successful Code 73
264 - 265 Secondary # Upload/Download Failed Code 74
TABLE 3-6: All 3+1, 4+1 and 4+2 Expanded Formats - Secondary
Address Description Setting
202 Secondary # Input Channel 1 Active Event Code 1
203 Secondary # Input Channel 2 Active Event Code F
204 Secondary # Input Channel 3 Active Event Code 8
205 Secondary # Input Channel 4 Active Event Code 9
206 Secondary # Input Channel 1 Fault Event Code F
207 Secondary # Input Channel 2 Fault Event Code F
208 Secondary # Input Channel 3 Fault Event Code F
209 Secondary # Input Channel 4 Fault Event Code F
210 Secondary # Phone Line 1 Voltage Fault Event Code 6
211 Secondary # Phone Line 2 Voltage Fault Event Code 6
212 Secondary # Phone Number 1 Comm.Fault Event Code 6
213 Secondary # Phone Number 2 Comm. Fault Event Code 6
214 Secondary # System Off Normal Fault Code 6
215 Secondary # Input Channel 1 Active Restoral Code E
TABLE 3-5: 4+2 Standard and 4+2 Express Formats - Secondary
Address Description Setting
