Fire-Lite 411UD User Manual

411UD Document #50759 Rev. E 12/09/2008 P/N 50759:E 29
Program Mode
All 3+1, 4+1 and 4+2 Expanded Formats Primary Central Station Event Codes
If 0, 2, 3, 4, 5, 6, 7, 8 ,9, B or D is entered for address 20, the following data is automatically programmed for the
Primary Central Station phone number event codes. Enter '0' for the Setting to disable the report to the Central
Station.
158 - 159 Primary # Phone Number 1 Comm. Fault Event Code 6A
160 - 161 Primary # Phone Number 2 Comm. Fault Event Code 6B
162 - 163 Primary # System Off Normal Fault Code 6F
164 - 165 Primary # Input Channel 1 Active Restoral Code E1
166 - 167 Primary # Input Channel 2 Active Restoral Code E2
168 - 169 Primary # Input Channel 3 Active Restoral Code E3
170 - 171 Primary # Input Channel 4 Active Restoral Code 93
172 - 173 Primary # Input Channel 1 Fault Restoral Code D1
174 - 175 Primary # Input Channel 2 Fault Restoral Code D2
176 - 177 Primary # Input Channel 3 Fault Restoral Code D3
178 - 179 Primary # Input Channel 4 Fault Restoral Code D4
180 - 181 Primary # Phone Line 1 Restoral Code A4
182 - 183 Primary # Phone Line 2 Restoral Code A5
184 - 185 Primary # Phone Number 1 Restoral Code AA
186 - 187 Primary # Phone Number 2 Restoral Code AB
188 - 189 Primary # System Off Normal Restoral Code AF
190 - 191 Primary # System Test Message 99
192 - 193 Primary # System Abnormal Test Message 91
194 - 195 Primary # Upload/Download Request Code 71
196 - 197 Primary # Upload Successful Code 72
198 - 199 Primary # Download Successful Code 73
200 - 201 Primary # Upload/Download Failed Code 74
TABLE 3-3: All 3+1, 4+1 and 4+2 Expanded Formats - Primary
Address Description Setting
138 Primary # Input Channel 1 Active Event Code 1
139 Primary # Input Channel 2 Active Event Code F
140 Primary # Input Channel 3 Active Event Code 8
141 Primary # Input Channel 4 Active Event Code 9
142 Primary # Input Channel 1 Fault Event Code F
143 Primary # Input Channel 2 Fault Event Code F
144 Primary # Input Channel 3 Fault Event Code F
145 Primary # Input Channel 4 Fault Event Code F
146 Primary # Phone Line 1 Voltage Fault Event Code 6
147 Primary # Phone Line 2 Voltage Fault Event Code 6
148 Primary # Phone Number 1 Comm. Fault Event Code 6
149 Primary # Phone Number 2 Comm. Fault Event Code 6
150 Primary # System Off Normal Fault Code 6
151 Primary # Input Channel 1 Active Restoral Code E
TABLE 3-2: 4+2 Standard and 4+2 Express Formats - Primary
Address Description Setting
