FIELD
TITLE and DATA ENTRIES
EXPLANATION
*59
Exit Error Report Code
0 = no report
1-F = see description above
After arming the system, entry/exit and interior zones remaining open
after exit delay expires cause an alarm sound at the keypad and
external sounder (keypad also displays “EXIT ALARM”), and entry
delay begins. Disarming before the end of the entry delay stops the
alarm sounding and no message is sent to the central station. The
keypad displays “CA” (fixed-word) or “CANCELED ALARM” (alpha
display).
If the system is not disarmed before entry delay expires, an “EXIT
ALARM” message will be sent to the central station if Exit Error
Report Code is enabled. The keypad will display “EA” (fixed-word ) or
“EXIT ALARM” (alpha display), and alarm sounding continues until
the system is disarmed (or timeout occurs).
An Exit Alarm condition will also result if a fault occurs in an exit or
interior zone within 2 minutes following the end of the exit delay,
and an “EXIT ALARM” message will be sent to the central station
1
With Contact ID format, the message will contain the zone number
and error code 374 (“ALARM–EXIT ERROR”).
*60
Trouble Report Code
0 = no report
1-F = see description above *59
This will be sent if a zone has a trouble condition.
UL: Required for UL commercial burglar alarm installations and
required for residential fire alarm installations.
*61
Bypass Report Code
0 = no report
1-F = see description above *59
This will be sent when a zone is manually bypassed.
UL: Required for UL commercial burglar alarm installations.
*62
AC Loss Report Code
0 = no report
1-F = see description above *59
Timing of this report is random with up to a 4-hour delay. If AC
restores before the report goes out, there is no “AC RESTORE”
report.
UL: Required for UL commercial burglar alarm installations and
required for residential fire alarm installations.
*63
Low Bat Report Code
0 = no report
1-F = see description above *59
Sent when a low-battery condition exists in the system’s battery.
UL: Required for UL commercial burglar alarm installations and
required for residential fire alarm installations.
*64
Test Report Code
0 = no report
1-F = see description above *59
† NOTE:
Make sure the Real-Time Clock
is set to the proper time
before
entering
the test report schedule command to
ensure that test reports are sent when
expected. (see Setting the Real-Time
Clock section on page 12-3)
Sent periodically to test that the communicator and phone lines are
operational.
Frequency of report is set in Scheduling mode
(event 11) or by the following key commands:
installer code + [#] + 0 + 0
= test report sent every 24 hrs
installer code + [#] + 0 + 1
= test report sent once per week
installer code + [#] + 0 + 2
= test report sent every 28 days
Each of these modes sets schedule 32 (FA168CPS) or 8
(FA148CP) to the selected repeat option; first test report sent
12 hours after command
†
.
UL: Required for UL commercial burglar alarm installations and
required for residential fire alarm installations.
*65
Open Report Code
0 = no report; 1-F = see description above *59
This is sent upon disarming of the system in the selected partitions.
UL: Required for UL commercial burglar alarm installations.
*66
Arm Away/Stay Report Code
0 = no report
1-F = see description above *59
This option allows for independent programming of Away and Stay
reports for each partition, including the common lobby.
NOTE:
“OPEN” reports are not sent if the associated closing report
is not enabled.
*67
RF Trans. Low Batt. Report Code
0 = no report; 1-F = see description above *59
Sent when a wireless transmitter low-battery condition exists.
UL installations: must be enabled if wireless devices are used.
*68
Cancel Report Code
0 = no report
1-F = see description above *59
This is sent upon disarming of the system after an alarm condition
was reported.
*70
Alarm Restore Report Code
0 = no report
1-F = see description above *59
Sent when an alarm zone is restored to its non-faulted condition.
UL: Required for UL commercial burglar alarm installations and
required for residential fire alarm installations.
*71
Trouble Restore Report Code
0 = no report
1-F = see description above *59
This is sent when a trouble in a zone is restored
UL: Required for UL commercial burglar alarm installations.
4-5
