38 FISCHERSCOPE
®
X-RAY
User Interface of the WinFTM Software
6.2.1 Zooming and Enlarging the Video Image
You can enlarge and zoom the video image to have a better view of the specimen and the meas-
urement spot and for focusing the video image.
To zoom in the video image
► Select in the WinFTM main menu Video > Zoom > 200% or 300% or 400%.
To set the zoom factor of the video image to its standard value, select in the WinFTM main
menu Video > Zoom > 100%.
To enlarge the video image
► Select in the WinFTM main menu Video > Video LARGE. Repeat this step to set the size of the
video image to its standard value.
6.2.2 Showing Programmed Coordinates
If you have programmed coordinates for automated measurements, you can show them in the video
image. The programmed coordinates appear as crosses in the video image.
To show programmed coordinates in the video image
► Select in the WinFTM main menu Video > Display X-Y Positions. The coordinates are displayed,
if the option is ticked.
6.2.3 Changing the Color of the Crosshairs
To increase the contrast between specimen and crosshairs, you can change the color of the cross-
hairs. Each click on the button (see Fig. 6.2 on Page 37) changes the color of the crosshairs. You
can choose between three different colors: black, white and one user-defined color.
To define a crosshairs color
1. Select in the WinFTM main menu Video > Crosshair color.
The window Color appears.
2. Select a color or define a new one.
3. Click OK.
