84 FISCHERSCOPE
®
X-RAY
(e.g., @SP1[150,90]).
NOTE: Note: You can only enter numbers in these fields if
the option box “Size user-defined” is checked.
10.8 Printing the Print Form Using the
Supplementary Software PDM
Print forms can be printed very easily when using the
supplementary software PDM.
Select the print form using the menu commands OR the
command buttons:
The
final print form evaluates only those blocks that have been
selected before for the final print form using “Evaluation”, sub-menu
“Block selection” or the command button “Block selection” (cf. figure
on the side).
Three options for printing the print form are available:
- Menu command “File > Print”, or
- Control command “CTRL-P” from the keyboard, or
- Clicking the command button “Printer” (cf. figure on the side)
Before printing, the print form can still be
edited (e.g., removing the
video image: Click the image and press the Del key) or text entered.
These changes disappear once the Print window is exited and
“Print form block evaluation” or “Print form final evaluation” is
selected again.
Icon for block evaluation Icon for final evaluation
Call using the menu command:
“Evaluation > Print form block
evaluation”
Call using the menu command:
“Evaluation > Print form final
evaluation”
