Special Features for SPC Charts Setting Up the Print Form Using PDM
FISCHERSCOPE
®
X-RAY 83
window “Measurement quantity selection”, the variable “@MW2”
will appear in the print form template.
NOTE: Note: The
variables must always be entered in upper
case letters!
NOTE: Note:
The character @ is part of the variable, i.e., it
must be entered, must not be deleted and it must not
be followed by space!
NOTE: Note:
Images that are located in the clipboard can be
inserted in the print form template using the menu
command mentioned below.
- Sub-program “Edit print form or print form template”
- Menu command "Edit > Insert"
Images saved in the BMP format can be inserted in the print form
template with the variable @VIF.
10.7 Special Features for SPC Charts
When the option box “all” is checked, the SPC charts of all
quantities to be measured (attributes) will be inserted in the print
form template one after the other.
If one of the option boxes “Measurement quantity 1”, "Measurement
quantity 2” or “Measurement quantity 3” is checked, only the SPC
chart of the respective measurement quantity will be inserted in the
print form template.
Option boxes “Maximum number of groups in the graphics”
Use these boxes to specify the maximum number of groups that will
be presented in the SPC chart.
Option boxes “Size”
When the option box “Standard” is checked, the SPC chart will
appear on the print form in the standard size.
If the option box “user-defined” is checked, the fields “Height” and
“Width” can be filled in to influence the size of the SPC chart to be
printed.
“Height” or “Width”
Use these fields to enter the height, or the width, of the SPC chart
to be printed.
The size specifications will appear in square brackets immediately
following the variable after inserting the variable in the print form
template
