FISCHERSCOPE
®
X-RAY 71
10 Setting Up the Print Form Using PDM
10.1 Statistical Evaluation and Documentation
Using the Supplementary Software PDM
The optional supplementary software PDM (product data
management) allows for a more convenient evaluation of the
measurement data than the basic version of WinFTM.
The simple block and final evaluation of the basic WinFTM software
continues to be available. In addition, product-related
documentation is possible
To print a print form, so-called print form templates are available to
the user, where - individually for each print form template - the
variables can be entered. These variables will be replaced by the
content of the actual value of the variable when printing the print
form.
In the supplementary software PDM, the user assigns to the
product a print form template for the block evaluation and a print
form template for the final evaluation.
Menu command for calling the respective dialog window:
“Product > Modify product”.
