Measurement Uncertainty and Measuring Ranges Display of the measurement uncertainty
90 FISCHERSCOPE
®
X-RAY
Tab. 2: Output of the measurement uncertainty of the single
readings
Tab. 3 Output of the measurement uncertainty of the mean
values
Systematic portion Computed from the
random error of the
calibration measure-
ment and the uncer-
tainties of the nominal
values of the stan-
dards, according to the
input in the "Calibra-
tion standard set"
Uses the error value of
the last measurement
of the block
Systematic + random
portion
Root of the squared
sum of the random
and the systematic
portions
Root of the squared
sum of the random
and the systematic
portions
Screen output Only for large number display, can be switched
off in "..\Measuring head parameter\Pre-set-
tings"
Output in block print
form
Not possible
Output in final print
form
Not possible
Export Output with every single reading, only with
Online-Export
Screen output Not possible
Output in block print
form
ONLY FOR THE RANDOM ERROR PORTION,
regardless of the error type setting
Output in final print
form
ONLY FOR THE RANDOM ERROR PORTION,
regardless of the error type setting
Export Output after each end of a block (block evalua-
tion), with On-line-Export. For Off-line (subse-
quently), only the random portion can be output.
