8
Machine information
Specifications
Name Model
number
Maximum
capacity
(kg)
Width
(mm)
Depth
(mm)
Depth with
door open
(mm)
Height
(mm)
WashSmart™ WH7060P1 7.0 600 590 1010 850
WashSmart™ WH8060P1 8.0 600 645 1065 850
QuickSmart™ WH7060J1 7.0 600 590 1010 850
QuickSmart™ WH8060J1 8.0 600 645 1065 850
Note: the exact height of your washer is dependent on how far the feet are extended from the
base of the machine. The space where you install your washer needs to be at least 40 mm wider
and 20 mm deeper than its dimensions.
Electrical supply: 220 – 240 V, 50 Hz Sinusoidal, 10 A
Inlet water static pressure: Max. 1 MPa (150 psi), Min. 30 kPa (4.5 psi)
Inlet water flow rate at tap: Min. 6 litres / min
Standpipe / tub height: 800 – 1200 min
