Fisher 399A - Page 33

* Recommended Spare Part.
1. Trademark of E. I. du Pont De Nemours Co.
Type 399A-161-112
26
Key Description Part Number
2 Bonnet (cont’d)
For 2 x 1-inch body 30B4342X022
For 2 and 4 x 2-inch body
Cast iron, 2-inch only 30B4342X012
WCB steel 30B4342X022
For 3-inch body
Cast iron 30B4349X012
WCB steel 30B4349X022
For 4, 6 x 4 and 8 x 4-inch body
Cast iron, 4-inch only 30B4356X012
WCB steel 30B4356X022
For 6, 8 x 6 and 12 x 6-inch body
WCB steel 30B7996X022
3 Cap Screw, pl steel
For 1-inch body (4 req’d) 1R281124052
For 1-1/4 x 1-inch body (4 req’d) 1R281124052
For 1-1/2 x 1-inch body (4 req’d) 1R281124052
For 2 x 1-inch body (8 req’d) 1A453324052
For 2 and 4 x 2-inch body (8 req’d) 1A453324052
For 3-inch body (8 req’d) 1A454124052
For 4, 6 x 4 and 8 x 4-inch body
(8 req’d) 1A440224052
For 6, 8x 6 and 12 x 6inch body
(12 req’d) 1U513124052
5* Flat Sheet Gasket, composition
For 1-inch body 14A6785X012
For 1-1/4 x 1-inch body 14A6785X012
For 1-1/2 x 1-inch body 1R2859X0042
For 2 x 1-inch body 14A5685X012
For 2 and 4 x 2-inch body 14A5685X012
For 3-inch body 14A5665X012
For 4, 6 x 4 and 8 x 4-inch body 14A5650X012
For 6, 8 x 6 and 12 x 6-inch body 14A6984X012
*6 Spiral Wound Gasket,
composition/S31603 stainless steel
For 1-inch body 1R286099282
For 1-1/4 x 1-inch body 1R286099282
For 1-1/2 x 1-inch body 1R286099282
For 2 x 1-inch body 1R329799282
For 2 and 4 x 2-inch body 1R329799282
For 3-inch body 1R348299282
For 4, 6 x 4 and 8 x 4-inch body 1R372299282
For 6, 8 x 6 and 12 x 6-inch body 1U508599282
7 Cage, heattreated stainless CrNi alloy
100% capacity
For 1-inch body 23B0940X012
For 2-inch body 23B0921X012
For 3-inch body 23B0941X012
For 4-inch body 23B0942X012
For 6-inch body 23B0943X012
60% capacity
For 1-inch body 23B8140X012
For 2-inch body 23B8069X012
For 3-inch body 23B8144X012
For 4-inch body 23B8079X012
For 6-inch body 23B8074X032
30% capacity
For 1-inch body 23B8140X022
For 2-inch body 23B8069X022
For 3-inch body 23B8144X022
For 4-inch body 23B8079X022
For 6-inch body 23B8074X012
Key Description Part Number
8* Cage O-Ring, nitrile rubber
For 1-inch body 14A5713X012
For 1-1/4 x 1-inch body 14A5713X012
For 1-1/2 x 1-inch body, nitrile 1H991206992
Fluoroelastomer 1R397106382
For 2 x 1-inch body 10B4428X012
For 2 and 4 x 2-inch body 10B4428X012
For 3-inch body 10B4366X012
For 4, 6 x 4 and 8 x 4-inch body 10B4373X012
For 6 and 12 x 6-inch body 1H862306992
9* Diaphragm See following table
10 Cage Retainer, aluminum
For 1-inch body 30B8000X012
For 1-1/4 x 1-inch body 30B8000X012
For 1-1/2 x 1-inch body 30B8000X012
For 2 x 1-inch body 30B8000X012
For 2 and 4 x 2-inch body 30B4339X012
For 3-inch body 30B4346X012
For 4, 6 x 4 and 8 x 4-inch body 30B4353X012
For 6, 8 x 6 and 12 x 6-inch body 30B7849X012
11 Diaphragm Support, hardanodized aluminum
For 1-inch body 10B8002X012
For 1-1/4 x 1-inch body 10B8002X012
For 1-1/2 x 1-inch body 10B8002X012
For 2 x 1-inch body 10B8002X012
For 2 and 4 x 2inch body 20B4337X012
For 3-inch body 20B4344X012
For 4, 6 x 4 and 8 x 4-inch body 20B4351X012
For 6, 8 x 6 and 12 x 6-inch body 20B7851X012
12 Diaphragm Spring, steel
For 1-inch body 14A9672X012
For 1-1/4 x 1-inch body 14A9672X012
For 1-1/2 x 1-inch body 14A9672X012
For 2 x 1-inch body 14A9672X012
For 2 and 4 x 2inch body 1H893327012
For 3-inch body 10B4400X012
For 4, 6 x 4 and 8 x 4-inch body 10B4378X012
For 6, 8 x 6 and 12 x 6-inch body 19A5976X012
13 Cage Retainer Bolt, S30300 stainless steel
For 1-inch body 10B8005X012
For 1-1/4 x 1-inch body 10B8005X012
For 1-1/2 x 1-inch body 10B8005X012
For 2 x 1-inch body 10B8005X012
For 2 and 4 x 2-inch body 10B4357X012
For 3-inch body 10B4364X012
For 4, 6 x 4 and 8 x 4-inch body 10B4371X012
For 6, 8 x 6 and 12 x 6-inch body
(18-8 stainless steel) 10B7854X012
14* Cage Retainer O-Ring, nitrile rubber
For 1-inch body 1V115706992
For 1-1/4 x 1-inch body 1V115706992
For 1-1/2 x 1-inch body, nitrile 1V115706992
Fluoroelastomer 10A0042X012
For 2 x 1-inch body 1V115706992
For 2 and 4 x 2-inch body 1K117706992
For 3-inch body 10A3800X012
For 4, 6 x 4 and 8 x 4-inch body 1D226906992
For 6, 8 x 6 and 12 x 6-inch body 1K181106992
15 Indicator Stem, S31600 stainless steel See following table
16 Indicator Spring, pl steel See following table
17 Stem O-Ring Retainer, polyethylene See following table
18* Indicator Stem O-Ring, nitrile rubber See following table
19 Indicator Stem Guide, heat-treated
stainless steel See following table
20 Indicator Disk, Delrin
(1)
10B4359X022
21 Indicator Scale, acrylic plastic See following table
