Fisher 399A - Page 34

Type 399A-161-112
27
Key 9. Diaphragm for Type 399A Main Valve
DESCRIPTION
BODY SIZE
DESCRIPTION
1-Inch 2-inch 3-inch 4-inch 6-inch
Nitrile
E55
Full Coat 20B8003X022 - - - 20B4368X022 20B4375X022 20B7852X022
Nitrile
E55
Partial Coat 22B2810X012 22B2811X012 22B2812X012 22B2813X012 22B2814X012
Nitrile
E54
Full Coat 20B8003X012 20B4417X012 20B4368X012 20B4375X012 20B7852X012
Nitrile
E54
Partial Coat 22B2810X022 22B2811X022 22B2812X022 22B2813X022 22B2814X022
Fluoroelastomer E66 Partial Coat 22B2810X032 22B2811X032 22B2812X032 22B2813X032 22B2814X032
Epichlorohydrin H3 Partial Coat 22B2810X042 22B2811X042 22B2812X042 22B2813X042 22B2814X042
Key 15, 16, 17, 18, 19, 20 and 21. Motion Indicator Parts for Type 399A Main Valve
BODY SIZE
KEY DESCRIPTION
1, 1-1/4 x 1, 1-1/2 x 1, 2,
2 x 1 & 4 x 2-inch
3-inch
4, 6, 6 x 4, 8 x 4,
8 x 6 & 12 x 6-inch
- - - Complete Motion Indicator Assembly 10B4360X0A2 10B4365X0A2 10B4372X0A2
15
16
17
18
19
20
21
Indicator Stem
Indicator Spring
O-ring Retainer
O-ring
Indicator Stem Guide
Indicator Disk
Indicator Scale
10B4360X012
10B4413X012
10B4422X012
1D134606992
20B4423X012
10B4359X022
10B4361X012
10B4365X012
10A4421X012
10B4422X012
1D134606992
20B4423X012
19B4359X022
10B4361X012
10B4372X0A2
10B4379X012
10B4422X012
1D134606992
20B4423X012
10B4359X022
10B4369X012
Key Description Part Number
22 Indicator Protector
For 1, 1-1/4 x 1, 1-1/2 x 1, 2 x 1,
2, 3 and 4 x 2-inch body 10B4362X012
For 4, 6, 6 x 4, 8 x 4, 8 x 6 and
12 x 6-inch body 24B1301X012
23 Inlet Strainer, 316 stainless steel
For 1-inch body 20B8004X012
For 1-1/4 x 1-inch body 20B8004X012
For 1-1/2 x 1-inch body 20B8004X012
For 2 x 1-inch body 20B8004X012
For 2 and 4 x 2-inch body 10B4409X012
For 3-inch body 20B4367X012
For 4, 6 x 4 and 8 x 4-inch body 20B4374X012
For 6, 8 x 6 and 12 x 6-inch body 20B7853X012
23 Optional Shim, 188 stainless steel
For 1-inch body 13B8061X012
For 1-1/4 x 1-inch body 13B8061X012
For 1-1/2 x 1-inch body 13B8061X012
For 2 x 1-inch body 13B8061X012
For 2 and 4 x 2-inch body 13B8062X012
For 3-inch body 13B8063X012
For 4, 6 x 4 and 8 x 4-inch body 13B8064X012
Key Description Part Number
For 6, 8 x 6 and 12 x 6-inch body
(S17400 stainless steel) 13B8065X012
24 Body Size/Serial Number Nameplate
Aluminum 
25 Flow Arrow, 18-8 stainless steel
For 1-inch body only 1V105938982
All other sizes 1V106038982
26 Drive Screw, 18-8 stainless steel (4 req’d) 1A368228982
27 Lubricant, , Dow Corning 33, (not furnished)
1 gallon (3.8 1) can 1M523906992
30 Drain Plug (for use only with bottom
tapped valve body), steel (not shown) 1A771528992
63 Pipe Plug, steel (2 req’d) 1A767524662
64 Pipe Plug
For 6, 8 x 6 and 12 x 6-inch body 1A767524662
65 Cage/Adaptor (not for 1, 2, 3, 4, or
6-inch body)
For 4 x 2-inch body 23B8621X012
For 6 x 4-inch body 23B8625X022
For 8 x 4-inch body 23B8625X012
For 8 x 6-inch body 23B8139X012
For 12 x 6-inch body 23B8139X022
