Fisher 399A - Page 40

Type 399A-161-112
33
Figure 20. Type 161, 161M, 161EB and 161EBM Pilots
VAPPL Y LUB
SENSE
(CONTROL) PORT
IN
PORT
BLEED (EXHAUST)
PORT
IN
PORT
OUT PORT (CONTROL)
GAUGE OR
OPTIONAL OUT
(CONTROL) PORT
TYPE 161M AND 161EBM
TYPE 161EB
TYPE 161
30B4395-E
CO806/IL
31B5012-A
