Type 399A-161-112
34
32B0707-B
C0808/IL
Figure 21. Type 161H, 161HM, 161EBH and 161EBHM Pilots
SENSE
(CONTROL) PORT
IN PORT
BLEED (EXHAUST)
PORT
IN PORT
OUT PORT (CONTROL)
GUAGE OR OPTIONAL
OUT (CONTROL) PORT
TYPE 161HM AND 161EBHM
TYPE 161H
TYPE 161EBH
V APPL Y LUB
32B0708-B
