flamco Sideflow Clean Pro - General Data; Components

9.2. General data
Sideflow Clean Pro
article number 17015
Max. operating pressure 8 bar
Max flow 5
m3
/h
Maximum temperature 80 °C
Filtration up to 1m
Glycol up to 50/50
Power supply 230 V
power consumption 160 W
Display size 4.3"
Weight 32 kg
Housing dimensions (H, W,
D in mm)
992 x 490 x 405
Width with connections 700 mm
connection 1 1/2“ BSP G
female thread
connections rotatable 360°
volume 45 dB
Languages German, English, French,
Dutch, Danish, Swedish,
Finnish, Polish
Ready for connection in an insulated housing
9.3. Components
9.3.1. recirculation pump
Maximum operating pressure 10 bar
ambient temperature -20 °C to 40 °C
Maximum media temperature 95 °C
Maximum relative humidity 95 %
Maximum throughput 5.1m/H
50 We reserve the right to change the design and technical specifications of our products.
