Getting to Know Your Inventor II
02
18
17
2
1
3
4
6
5
7
8
9
10
11
12
13
14
15
16
1. Z-Axis Guide Rod
16. Turbo Fan
14. Nozzle
8. Touch Screen Button
3. Filament Cartridge
7. Touch Screen
5. Y-Axis Guide Rod
9. Build Plate
10. Leveling Knob
12. USB Stick Input
17. Power Switch
18. Power Input
2. Filament Outlet 4. Filament Inlet
6. X-Axis Guide Rod
13. Servo
11. USB Cable Input
15. Turbo Fan Baffle
