Flow Data & Injector Draw Rates - Downflow
TR 22089 - 2900s valve 1700 Series Injector Draw Rates
0.5
0.7
0.9
1.1
1.3
1.5
1.7
1.9
2.1
2.3
2.5
2.7
2.9
3.1
3.3
0 10 20 30 40 50 60 70 80 90 100 110 120 130 140
Inlet Pressure - psi
Flow Rate - gpm
# 3C # 4C # 5C # 6C
