Flex innovations FV-31 Cypher - FLEXF3 Wiring Diagram

MICRO USB
(uses UART1)
PPM
UART 3
(RX INPUT)
GND 4.3V
GND
VBATT
GND
5V
TX2
RX2
4.3V
GND
BOOT
A B C D E F G H
1
2
3
MTR 3 (ORANGE)
MTR 4 (YELLOW)
MTR 2 (VIOLET)
A
1
2
3
MTR 1 (GREEN)
5V (BEC INPUT)
GND (BLACK)
B
1
2
3
R ELEVON
5V
GND
C
1
2
3
L ELEVON
5V
GND
D
1
2
3
FAN TILT
5V
GND
E
1
2
3
NOSEWHEEL
5V
GND
F
1
2
3
CH9
5V
GND
G
1
2
3
CH8
5V
GND
H
1
2
3
RX3
TX3
43
UART2
BLUETOOTH
(19200 BAUD)
BUZZER/LED
FLIGHT PACK
VOLTAGE INPUT
S
4.3V
GND
FLEXF3
REFERENCE
DIAGRAM
BLUE LED
(POWER)
RED LED
(STATUS)
