Operators and Reference Manual
MC12 OM RM EN 74-111-132 v1.03.doc Ver. 1.03 Page 10 of 47
6. PROGRAMMING
6.1 Starting the MC12
In the following, the sign <> will mean that the indicated key must be activated. For instance,
<ENT> means that ENTER must be pressed.
When the MC12 is connected, the main switch on the left side of the control box can be
turned on. The display will show the following:
Figure 5 – Starting MC12 -I
Press the <GO> key, and the display will show the following:
* MC12 V1.XX (C) Flexicon 90-XX *
PRESS GO TO CONTINUE.
Figure 6 – Starting MC12 -II
Verify that all connected drives are displayed with their respective numbers.
Then press <GO> once more, and the display will show the following:
F 1: 100.00 ml.
F 3: 200 rpm
F 2: 8.0 TUBE
F 4: 10 ACC
Figure 7 – Starting MC12 -III
The values shown in the status lines will be the above or the latest values used.
Please note – that in MC12 special versions, pressing the GO key during start up is put out
of commission. Start-up runs without pressing GO.
6.2 Password Protection
MC12 is password protected. To be able to perform the following programming procedures it
is necessary to log on as a supervisor (see function 59).
Always remember to change the password level back to user level after programming.
Remember that merely switching MC12 off/on will NOT change any selected password level!
