5. CONTROL
5.1 Display
The display of MC12 consists of 4 lines each of 40 characters.
The display is lit from the back.
The blinking cursor of the display shows where a character will occur, if a key is activated.
F 1: 100.00 ml.
F 3: 200 rpm
F 2: 8.0 TUBE
F 4: 10 ACC
Figure 3 - Display
The top line is the typing line and also the line, where MC12 prompts the operator.
The second last character on the top line (X) indicates the operation principle of MC12:
Individual (I), Parallel (P) and Serial (S)
The ultimate character of the top line (1) indicates the pump connected.
The three lines below are status lines which always shows the current operating parameters.
These status lines can be scrolled by pressing the Up or Down Arrow of the keyboard.
When operating MC12, it is VERY important to watch the top line constantly, as any current
question or instruction will be written here.
