FLUXUS F70x 11 Advanced Measuring Functions
110 UMFLUXUS_F7V4-6-2EN, 2017-10-01
Activating the FastFood mode
Quitting the configuration
Assigning the binary input
After the editing of the remote function, it is determined which binary input is to be used to trigger this function.
After assigning the binary input, it is possible to activate additional remote functions for the channel selected previously. If
the configuration of the remote functions is complete, the menu item can be left by pressing BRK. All new settings will be
accepted.
11.10.1.2 Copying the Remote Function
If a remote function has already been configured for a channel, its configuration can be copied to the currently selected
channel.
11.10.2 Resetting the Remote Function
Select the list item
FastFoodMode. Press ENTER.
The FastFood mode is activated for the duration of the switching signal.
The FastFood mode is deactivated when the voltage at the binary input is switched back to
the passive range.
This list item is only available for measuring channels.
For more information regarding the FastFood mode see section 11.7.
Select the list item
go back. Press ENTER.
Editing of the remote function is stopped. The menu item Remote inputs is displayed.
Select the binary input (
Binary Input S1
or
Binary Input S2
) which is to be used to
trigger the previously selected remote function (here:
clear totals
)
. To deactivate the re-
mote function, select NO INPUT. Press ENTER.
This display will only be indicated if the transmitter is equipped with 2 binary inputs.
After assigning the binary input, the menu item Remote-Func. is displayed again.
Select the channel (here:
B
) from which the remote function configuration is to be copied to
the currently selected channel.
Press ENTER.
Select
Special Funct.\SYSTEM settings
\
Remote inputs. Press ENTER.
Select the channel for which the remote function is to be reset. Press ENTER.
Select the list item
Clear all
.
A request is displayed if the remote function is to be reset. Select yes. Press ENTER.
A: Remote-Func. ↕
FastFoodMode
A: clear totals ↕
Binary Input S1
SYSTEM settings↕
Remote inputs
Remote inputs ↕
for Channel
Remote inputs ↕
A: Clear all
