B U F F E R S A N D S A M P L E R A T E A P P E N D I X A
Figure 181: 25Hz CWL Filter at 48kHz Sample Rate
203  2003-2008 FlexRadio Systems
Figure 182: 25Hz CWL filter at 96kHz Sample Rate
DSP Buffer Sizes:
Red – 512
Green – 1024
Blue – 2048
Black - 4096
Figure 183: 25Hz CWL Filter at 192kHz Sample Rate
DSP Buffer Sizes:
Red – 512
Green – 1024
Blue – 2048
Black - 4096
DSP Buffer Sizes:
Red – 512
Green – 1024
Blue – 2048
Black - 4096
