FLIR M4200 SERIES - Page 186

M4200 Series System Specifications
27
Power Consumption Approx. 15 watts (No HDD Installed)
Supply Voltage 4/8 ch: 100VAC-240VAC, 12VDC, 4A, 50/60Hz
Unit Dimensions (W x D x H) 14.7" x 11.2" x 2.2"
375mm x 285mm x 55mm
Unit Weight 5.2lbs (without HDD)
2.4KG (without HDD)
Operating Temperature 32° ~ 104° F / 0° ~ 40° C
Humidity 10 ~ 90% RH
Recording Resolution (Pixels) & Speed (FPS - Frames per second)
Model
FPS (NTSC/PAL)
960H (960x480/
960x576)
720P
1280x720
1080P
1920x1080
4ch
Total 120/100 120/100 120/100
Per channel 30/25 30/25 30/25
8ch
Total 240/200 240/200 240/200
Per channel 30/25 30/25 30/25
As our products are subject to continuous improvement, FLIR Systems, Inc. and its sub-
sidiaries reserve the right to modify product design, specifications, and prices without no-
tice and without incurring any obligation. E&OE
#LX400051; r. 1.0/23100/23101; en-US
176
