Using the Main Menu17

17.1.6 Selecting Cable Type

The Cable Type menu is used only if you are using cabling with a resistance higher than

10Ω per 100m (330ft) and you are having picture quality issues. Select the UTP option for

any channels having the issue. In all other installations, use the Coaxial setting. Click OK

to save your changes.
