FLIR Nexus - Restoring the Factory Settings

3-18 427-0030-00-28 Version 110 Jun 2013
3
Advanced Configuration
3.10 Restoring the Factory Settings
The camera comes configured from the factory with default settings for the IP address
(192.168.250.116), the login password (fliradmin), and all of the other configuration parameters
(stored in a file called server.ini). In some cases, it may be necessary to restore the settings of the
camera to the original factory settings. If necessary, this can be accomplished by temporarily
connecting a loopback device to the Ethernet port during initial power-up
2
. Approximately 30 seconds
after power is turned on, the loopback should be removed to allow the camera to finish booting up.
Note
At each power-up, the system transmits a packet and then checks to determine if that same packet
has been received. Detection of the received packet indicates the camera has a custom loopback
connector installed on its Ethernet interface. The detection of the loopback packet cues the camera to
restore Factory Defaults (including the IP settings, user passwords, and configuration file), reverting to
the same configuration and behavior as when the camera left the factory.
The custom loopback connector is described below.
The RJ45 loopback termination ties pin 1 to pin 3, and pin 2 to pin 6. The other pins are not
connected. This type of device is available commercially (the Smartronix Superlooper Ethernet
2. For cameras with PoE capabilities, this method is not possible if the camera is connected
to a PoE switch. It will work if the camera uses conventional power rather than PoE, or if
the camera is connected to a PoE injector and the loopback is connected to the port that is
unpowered.
The camera will not finish booting up while the loopback device is connected to the camera. The
camera will display analog video, but the Nexus Server will not start until the loopback is removed
from the camera.
Pin # Signal Tied to pin #
1 Tran s m it + 3
2 Tr a n sm i t - 6
3 Receive + 1
4 Unused N/A
5 Unused N/A
6 Receive - 2
7 Unused N/A
8 Unused N/A
