427-0030-00-28 Version 110 Jun 2013 3-19
3
Advanced Configuration
Loopback Jack and Plug is one example), or it can be easily made with an RJ45 plug, a couple wires,
and a crimp tool.
Important Note
After the camera boots up, confirm the startup information is displayed on the analog monitor after
approximately 90 seconds. For example:
S/N: 1234567
IP Addr: 192.168.250.116
For cameras with serial communications capability, the additional serial configuration information will
be displayed also.
The camera will not finish booting up while the loopback is connected to the Ethernet. Approximately
30 seconds after power is turned on, the loopback should be removed to allow the camera to finish
booting up.
