427-0026-01-10, version 110 Oct 2010
7
3 – Getting Started
Figure
3-1:
PatrolIR B Pan and Tilt
Monitor
(not supplied)
BNC
Joystick Control Unit
Ground wire
Monitor cable
(not supplied)
12 VDC
5A Fuse
Return
PatrolIR Camera
Ground wire
30 “
22 feet
2
2
f
e
e
t
connector
BNC to RCA adapter
(supplied)
Junction bo
x
(not supplied)
10
12
