427-0026-01-10, version 110 Oct 2010 5
3 Getting Started
3.1 Parts List
The PatrolIR B camera and its accessories are delivered in a box
which contains the items below.
3.2 Operational Overview
The PatrolIR B is easy to install and operate. The system operates
on 12 volts DC and there are no camera adjustments. The thermal
imaging camera inside the PatrolIR B is completely sealed and
extremely rugged. The camera has been qualified for operation in all
types of weather conditions over the specified operating
temperature range and includes an automatic window heater that
will prevent icing under most conditions.
• PatrolIR B camera with attached 30" integrated cables with
connectors
• Joystick Control Unit cable, 22' long
• Video cable with BNC video connector 22' long
• Pre-Wired Joystick Control Unit (JCU) with integrated power
cable (fuse holder, power leads)
Two JCU models available; they are functionally the same but
one is intended to be mounted horizontally and the other is
mounted vertically.
Camera FLIR PN
White color, NTSC, Horiz JCU 427-0026-01-00
White color, NTSC Export, Horiz JCU 427-0026-01-00S
White color, PAL, Horiz JCU 427-0026-02-00
White color, PAL Export, Horiz JCU 427-0026-02-00S
White color, NTSC, Vert JCU 427-0026-03-00
White color, NTSC Export, Vert JCU 427-0026-03-00S
White color, PAL, Vert JCU 427-0026-04-00
White color, PAL Export, Vert JCU 427-0026-04-00S
Mounting hardware for the camera, mounting hardware for the
Joystick Control Unit, 5-amp fuses, cable clips, and extra
electrical components
PatrolIR B Pan and Tilt User’s Guide 427-0026-01-10
